Single Study Plans are Only Available as Digital Downloads

Designed by John Alden

A Swampscott dory-type daysailer with generous side decks and inside ballast.

LOA - 21' 2"
LWL - 16' 9"
Beam - 6' 4"
Draft (cb up) - 18"
(cb down) - 3' 6"
Displ. - 1,200 lbs.
Sail Area - 196 - 230 sq. ft.
Construction Method: Lapstrake over sawn frames
Lofting is required: Partial
Skill level: Intermediate to Advanced
Plans include 4 sheets, plus specification supplement.



————————————————————

“Your downloads are ready” will be the subject line of an email you’ll receive from us—once we’ve processed your digital order. That email has the link to click, so you can then download the file.

This isn't an "instant" process, so if we're asleep, you may need to wait for regular business hours for us to process the order. Although we are quite timely, we may not be processing on weekends & holidays.
